PRODUCT DETAILS · VERIFIED SYSTEM IDENTITY

Baker Hughes official datasheet · 161581 Rev. AC

BENTLY NEVADA3500 MACHINERY PROTECTION SYSTEM

3500/22M

Transient Data Interface Module

The rack communication and data-collection interface for compatible System 1 condition monitoring and 3500 configuration software.

CONDITION

New Original

WARRANTY

One year

IN STOCK

3 units

OFFICIAL SOURCE

161581 Rev. AC

SYSTEM CONNECTION

Data route

3500 Rack

3500/22M TDI

Ethernet Link

System 1

PRODUCT POSITIONING

The communication core of a 3500 rack

Collects steady-state and transient data from compatible monitors and passes it to host software over Ethernet.

ORDERING STRUCTURE

3500/22-AA-BB-CC

AA · TDI type
BB · I/O module type
CC · agency approval

Compatibility

Interfaces with M-series monitors such as 3500/40M and 3500/42M. One TDI or RIM is required in every rack.

MANUFACTURER

Baker Hughes

BRAND

Bently Nevada

MODEL

3500/22M

OFFICIAL PRODUCT

Transient Data Interface Module

SYSTEM FAMILY

3500 Machinery Protection System

POWER CONSUMPTION

10.5 W

FRONT CONFIGURATION PORT

USB-B

ETHERNET INTERFACES

10Base-T/100Base-TX or 100Base-FX

RACK POSITION

Slot 1, adjacent to power supplies

OPERATING TEMPERATURE

-30°C to +65°C

Continuous collection

Captures steady-state and transient waveform data from compatible monitor channels.

Dual software link

Supports 3500 configuration tools and System 1 condition monitoring software.

Rack-wide interface

Provides configuration access, rack status and host communication from Slot 1.

APPLICATION MAP

3500 rack communication and machinery data access

Turbine trains

Transfers vibration and position data from critical rotating assets.

Compressors

Supports rack configuration and condition-monitoring data access.

Generators

Connects machinery protection racks with host diagnostic software.

Plantwide monitoring

Provides Ethernet access to compatible System 1 environments.

3500/22M Transient Data Interface

3500 Machinery Protection System

3500/22M Datasheet
