PRODUCT DETAILS · SIEMENS

6DD1610-0AH6

SIMATIC TDC MC510 Program Memory Module

PRODUCT SERIES

SIMATIC TDC

PRODUCT IDENTITY

Siemens 6DD1610-0AH6 SIMATIC TDC MC510 Program Memory Module, 8 MB is a removable 8 MB non-volatile program-memory module for SIMATIC TDC CPU550 and CPU551 processors.

CONDITION

New Original

WARRANTY

One year

AVAILABILITY

In stock

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Technical configuration and compliance

PRODUCT DESCRIPTION

The MC510 stores the processor configuration created with HW Config and CFC, including the operating system. It installs in the CPU submodule slot and can be programmed offline through a PCMCIA adapter or online over the installed CPU serial service connection.

CERTIFICATIONS & STANDARDS

◆ EU EMC Directive · 2014/30/EU

◆ EU RoHS Directive · 2011/65/EU

◆ UK EMC Regulations · S.I. 2016 No. 1091

◆ UK RoHS Regulations · S.I. 2012 No. 3032

OFFICIAL TECHNICAL DATA

DESIGNATION

MC510

FUNCTION

Program memory module

PROGRAM CAPACITY

8 MB

MEMORY TECHNOLOGY

Non-volatile program memory

STORED CONTENT

HW Config / CFC project and operating system

HOST PROCESSOR

SIMATIC TDC CPU550

ALTERNATE HOST

SIMATIC TDC CPU551

MECHANICAL INTERFACE

CPU submodule slot

OFFLINE LOADING

PCMCIA PC-card programming adapter

ONLINE LOADING

Installed CPU serial service connection

RECOMMAND · APPLICATION GUIDANCE

Operational guidance and related products

DIAGNOSTICS & PROTECTION

The MC510 has no autonomous diagnostic interface. CFC and CPU service functions report project size and available program memory; Siemens SIMATIC TDC ESD handling rules apply during replacement.

OPERATING ENVIRONMENT

The module operates inside the CPU550 or CPU551 submodule bay and follows the host CPU and rack environmental limits. Siemens does not publish separate ambient ratings for the MC510.
