PRODUCT DETAILSSIEMENS

ARTICLE NUMBER

6ES7134-6GD01-0BA1

Warranty: One year • Availability: In stock

OFFICIAL PRODUCT NAME

SIMATIC ET 200SP AI 4xI 2-/4-Wire ST Analog Input Module

SIMATIC ET 200SP / Analog Input Modules

Description: Digitizes four current signals with module diagnostics and 16-bit resolution on ET 200SP BaseUnits A0 or A1.

Tel : +86 17359287459Email : sales9@apterpower.com

SPECIFICATIONS / OFFICIAL ENGINEERING DATA

6ES7134-6GD01-0BA1 FUNCTIONAL PROFILE

The ET 200SP AI 4xI 2-/4-wire ST module measures four current signals from two-wire or four-wire transmitters. It provides module diagnostics, 16-bit conversion and I&M data for compact distributed-I/O applications.

OFFICIAL TECHNICAL DATA

Article number

6ES7134-6GD01-0BA1

Product type

KEY-PLUG XM-400 Layer 3 Routing

Compatible platform

SCALANCE XM-400

Storage medium

KEY-PLUG

Storage capacity

256 MiB

Layer 3 activation

Supported

Configuration storage

Supported

Device replacement support

Supported

Degree of protection

IP20

Lifecycle status

Phase-out since 01.10.2025

OPERATING ENVIRONMENT

Operation is specified from -30 to +60 °C for horizontal mounting and to +50 °C for vertical mounting; installation altitude is permitted up to 5,000 m subject to documented restrictions.

INSTALLATION & UPGRADE

Install on an ET 200SP BaseUnit type A0 or A1 and apply color code CC03. Configure in TIA Portal V14 or later, then verify channel measuring ranges, wiring mode and module diagnostics.

RECOMMAND

SAFETY & COMPLIANCE

EU and UK conformity declarations and China RoHS documentation are available from Siemens. Reverse-polarity protection and short-circuit-protected sensor supply support controlled commissioning.

PERFORMANCE EFFICIENCY

Four 16-bit current channels in a 15 mm ET 200SP format provide compact signal density; reparameterization in RUN minimizes interruption when measurement settings change.
