PRODUCT DETAILS

SIEMENS

ARTICLE NUMBER

6ES7650-1AH61-5XX0

Warranty: One year • Availability: In stock

OFFICIAL PRODUCT NAME

SIMATIC PCS 7 F-AI HART MTA Connection Module

Series: SIMATIC PCS 7 / MTA
Description: Six-channel fail-safe analog input HART marshalling terminal assembly for SIMATIC PCS 7 field connections.

RELATED MODELS ON EWOLOMODULE
6GK1161-6AA01 6SL3210-1PE22-7AL0 6ES7313-5BF03-0AB0

SPECIFICATIONS / OFFICIAL ENGINEERING DATA

PCS 7 F-AI HART MTA engineering profile

The MTA provides a structured six-channel connection level for fail-safe HART analog input signals and interfaces the field wiring with the associated SIMATIC PCS 7 I/O configuration.

OFFICIAL TECHNICAL DATA

Article number

6ES7650-1AH61-5XX0

Module type

F-AI HART MTA

Channels

Rated supply

24 V DC

Supply range

21.6 to 28.8 V DC

Normal current

0.5 A max.

Channel fuse

0.1 A fast

Module fuse

0.5 A

Conductor range

24 to 14 AWG

Operating temperature

-25 °C to +60 °C

DIAGNOSTIC PROTECTION

Channel and power status indicators, fuse protection and the fail-safe signal path support diagnostic visibility and safety-oriented maintenance.

PERFORMANCE EFFICIENCY

Six HART-capable fail-safe input connections centralize field termination and simplify structured marshalling in PCS 7 installations.

RECOMMAND

INSTALLATION & UPGRADE

Mount on a 35 mm DIN rail, connect the documented 24 V DC supply and field terminals, and verify the associated fail-safe I/O assignment and HART configuration.

APPLICATION SCENARIOS

Safety-related process measurement, chemical and energy plants, pharmaceutical systems and PCS 7 field-instrument marshalling.
