PRODUCT DETAILS · SIEMENS

6ES7972-0AA02-0XA0

SIMATIC DP RS485 Repeater for PROFIBUS/MPI

PRODUCT IDENTITY

Siemens 6ES7972-0AA02-0XA0 SIMATIC DP RS485 Repeater

A compact signal repeater that links and regenerates PROFIBUS or MPI bus segments at transmission rates up to 12 Mbit/s.

Product series: RS 485 repeater for PROFIBUS

TEL
+86 17359287459

EMAIL
sales9@apterpower.com

RELATED MODELS

6ES7972-0AB01-0XA0

6AG1972-0AA02-7XA0

6ES7972-0AA01-0XA0

6ES7972-0AB00-0XA0

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Signal repetition and network compatibility

PRODUCT DESCRIPTION

The repeater amplifies RS485 bus signals and links two PROFIBUS or MPI segments. It detects the transmission rate automatically and provides separate segment connections, termination switches, a PG/OP interface and status LEDs for the supply and both bus segments.

OFFICIAL TECHNICAL DATA

Product designation	RS 485 Repeater	Bus systems	PROFIBUS / MPI
Connected nodes	Max. 31	Transmission rate	9.6 kbit/s to 12 Mbit/s
Rated supply	24 V DC	Permissible supply	20.4–28.8 V DC
Power loss, typical	0.7 W	Degree of protection	IP20

CERTIFICATIONS & STANDARDS

◆ Siemens industrial communication requirements for PROFIBUS/MPI RS485 networks

◆ IP20 equipment for protected control-cabinet installation

◆ RoHS compliant according to the official product record

COMPATIBILITY & INTEROPERABILITY

◆ PROFIBUS and MPI RS485 bus systems

◆ Automatic transmission-rate detection up to 12 Mbit/s

◆ Standard DIN rail or SIMATIC S7-300 mounting rail

RECOMMAND

Lifecycle handling and product selection

FIRMWARE UPDATES

◆ No user-loadable firmware is specified for this hardware repeater

◆ The transmission rate is detected automatically

◆ Verify bus settings and termination during replacement

CONFIGURATION & PROGRAMMING

◆ No application program is required for signal repetition

◆ Set termination switches for both bus segments as required

◆ Check the PG/OP load and 24 V DC supply before commissioning
