PRODUCT DETAILS

SIEMENS

ARTICLE NUMBER6ES7972-0BB51-0XA0

OFFICIAL PRODUCT NAME

SIMATIC DP PROFIBUS FastConnect Bus Connector

FastConnect PROFIBUS bus connector for transmission rates up to 12 Mbit/s, combining a 90° cable outlet, PG interface and switchable segment termination.

WARRANTY

One year

AVAILABILITY

In stock

TEL

+86 17359287459

sales9@apterpower.com

INSTALLATION, UPGRADES & FIRMWARE

TRANSFER RATEUp to 12 Mbit/s

CABLE OUTLET90°

TERMINATIONFastConnect

PG INTERFACEFitted

INSTALLATION & UPGRADE

FIRMWARE & UPDATES

01Prepare the PROFIBUS cable for the FastConnect insulation-displacement contacts.

PASSIVE DEVICEThe connector contains no firmware, software image or parameter storage.

02Route the cable through the 90° outlet and secure the connector to the RS485 interface.

UPDATE SCOPENo firmware update applies; maintenance is limited to wiring and hardware condition.

03Switch termination on only when the device is at the corresponding bus-segment end.

NETWORK CHECKConfirm cable continuity, shielding, termination and station accessibility.

04Use the PG interface for service access and verify communication after installation.

SUCCESSOR REVIEWMatch 90° geometry, FastConnect system and PG interface before substitution.

BRAND CHARACTERISTICS & APPLICATION FIELDS

BRAND CHARACTERISTICS

APPLICATION FIELDS

◆ FastConnect termination supports rapid compatible-cable installation.

◆ PROFIBUS DP commissioning and maintenance connections.

◆ The PG interface provides convenient PROFIBUS service access.

◆ SIMATIC controller and distributed-I/O network links.

◆ A 90° outlet aids compact cabinet cable management.

◆ Control cabinets requiring right-angle cable routing.

◆ Switchable termination supports defined bus-segment endpoints.

◆ Lifecycle replacement of installed RS485 bus connectors.
