PRODUCT DETAILS

6ES7972-0EM00-0XA0

SIMATIC S7 TS Adapter IE Modem

PRODUCT IDENTITY

Siemens 6ES7972-0EM00-0XA0 SIMATIC S7 TS Adapter IE Modem

A 24 V DC TeleService adapter that links Ethernet-connected SIMATIC automation systems to an analog telephone network for remote maintenance.

CONDITIONNew Original

WARRANTYOne year

AVAILABILITYIn stock

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Standards, system fit and core data

CERTIFICATIONS & STANDARDS

◆Product declaration covers EN 55032 electromagnetic emissions

◆Product declaration covers EN 55024 immunity requirements

◆Industrial immunity compliance is documented to EN 61000-6-2

◆Industrial emissions compliance is documented to EN 61000-6-4

COMPATIBILITY & INTEROPERABILITY

◆TeleService access for SIMATIC S7-200, S7-300, S7-400 and C7 systems

◆Ethernet connection through RJ45 at 10/100 Mbit/s

◆Integrated analog modem connects to the public analog telephone network through RJ11

◆TeleService software provides administration and remote-maintenance functions

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATION

TS Adapter IE Modem

AUTOMATION INTERFACE

Ethernet

ETHERNET RATE

10 / 100 Mbit/s

MODEM INTERFACE

Analog modem / RJ11

SERIAL INTERFACE

RS232; max. 115 kbit/s

RATED SUPPLY

24 V DC

SUPPLY RANGE

20.4–28.8 V DC

CURRENT, TYP.

180 mA

CURRENT, MAX.

240 mA

POWER INPUT, TYP.

4.32 W

RECOMMAND

Firmware, configuration and related models

FIRMWARE UPDATE

CONFIGURATION & PROGRAMMING

◆Read and record the adapter firmware and hardware release in the administration page

◆Open the TS Adapter IE administration function from Siemens TeleService

◆Use only firmware and service procedures released by Siemens for the exact adapter type

◆Set Ethernet addressing, modem parameters and access credentials before remote use

◆Preserve network, modem and user settings before maintenance or replacement

◆Connect the external 24 V supply and verify the Ethernet and telephone interfaces
