PRODUCT DETAILS

6GK1161-3AA00

SIMATIC NET CP 1613 PCI Communication Processor

PRODUCT IDENTITY

Siemens 6GK1161-3AA00 SIMATIC NET CP 1613 PCI Communication Processor

A HARDNET PCI communications processor with RJ45 and ITP connectivity for legacy S7, PG, TF and fault-tolerant Industrial Ethernet communication.

CONDITIONNew Original

WARRANTYOne year

AVAILABILITYIn stock

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Standards, system fit and core data

CERTIFICATIONS & STANDARDS

◆Industrial communication hardware documented under the SIMATIC NET product framework

◆PCI host interface follows the documented 32-bit, 33 MHz, 5 V card specification

◆Industrial Ethernet interface intended for use with Siemens-approved system components

◆Installation and operation are subject to the EMC and safety instructions in the CP documentation

COMPATIBILITY & INTEROPERABILITY

◆Connects a PG or industrial PC to 10/100 Mbit/s Industrial Ethernet

◆Supports S7-1613, TF-1613, PG-1613 and S7-REDCONNECT software packages

◆Works with ISO transport and ISO-on-TCP communication to SIMATIC S7 systems

◆Requires a legacy PCI slot and a supported 32-bit Microsoft Windows environment

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATION

CP 1613

PROCESSOR CLASS

SIMATIC NET HARDNET

HOST INTERFACE

32-bit PCI

PCI CLOCK

33 MHz

PCI SIGNAL VOLTAGE

5 V

NETWORK

Industrial Ethernet

TRANSFER RATE

10 / 100 Mbit/s

NETWORK PORTS

RJ45 and 15-pin ITP

COMMUNICATION PACKAGES

S7-1613 / TF-1613 / PG-1613

SUCCESSOR

6GK1161-3AA01 CP 1613 A2

RECOMMAND

Firmware, configuration and related models

FIRMWARE UPDATE

CONFIGURATION & PROGRAMMING

◆Record the CP firmware and SIMATIC NET software version before service work

◆Configure the PC station with NCM PC or STEP 7 and the matching SIMATIC NET package

◆Use a SIMATIC NET software release that still supports the CP 1613 without A2 suffix

◆Assign the Industrial Ethernet protocol and S7ONLINE access point consistently

◆Preserve the PC-station configuration before replacing the processor or software stack

◆Select RJ45 or ITP cabling according to the installed network infrastructure

6GK1161-3AA00 Communication Processor

Industrial Ethernet Module
