PRODUCT DETAILS

6GK5208-0BA10-2AA3

SCALANCE X208 Managed Industrial Ethernet Switch

PRODUCT IDENTITY

Siemens 6GK5208-0BA10-2AA3 SCALANCE X208 Managed Industrial Ethernet Switch

A compact managed switch with redundant 24 V DC input, eight Fast Ethernet ports, integrated redundancy management and optional C-PLUG storage.

CONDITIONNew Original

WARRANTYOne year

AVAILABILITYIn stock

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Standards, system fit and core data

CERTIFICATIONS & STANDARDS

◆CE marking documented for the SCALANCE X product family

◆RCM supplier declaration includes 6GK5208-0BA10-2AA3

◆IECEx certification lists the X208 for T4 operation from -40 to +60 °C

◆Bureau Veritas type approval includes the SCALANCE X208

COMPATIBILITY & INTEROPERABILITY

◆Eight RJ45 ports support 10 and 100 Mbit/s Industrial Ethernet

◆PROFINET IO device functionality with conformity class B diagnostics

◆Management through CLI, web-based management, STEP 7 and SNMP v1/v2/v3

◆MRP and high-speed ring redundancy are supported; C-PLUG is optional

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATION

SCALANCE X208

COPPER PORTS

8 × RJ45

TRANSFER RATE

10 / 100 Mbit/s

SUPPLY VOLTAGE

24 V DC

MAX. CURRENT

0.185 A

POWER LOSS

3.84 W

SIGNALING CONTACT

24 V DC / 0.1 A max.

PROTECTION CLASS

IP30

OPERATING TEMPERATURE

-40 to +60 °C

PROFINET CLASS

Conformity Class B

RECOMMAND

Firmware, configuration and related models

FIRMWARE UPDATE

CONFIGURATION & PROGRAMMING

◆Record the hardware product version and installed firmware before updating

◆Commission with web-based management, CLI or STEP 7

◆Back up the switch configuration to the optional C-PLUG or an engineering station

◆Assign the PROFINET device name, IP parameters and diagnostic behavior

◆Install only a Siemens firmware release approved for the SCALANCE X208 hardware version

◆Configure MRP or ring-redundancy roles consistently across the network

6GK5208-0BA10-2AA3 Ethernet Switch

SCALANCE Switch Datasheet
